Metarc ARC 400IJ2-500IJ-630I / Supplier And Exporter
Heavy Industrial, Classical ... The priority selection for Heavy Engineering fabrication industry with heavy duty.
Processes:
• MMA
• Remote Control
• Carbon Arc Gouge
Package includes:
• Inverter Power Source
• Electrode Holder 3m
• Earth Clamp 3m
Optional Accessories:
• Quick Plug
• Wrench
• Remote Control Box
• Helmet
Features:
• Heavy duty, non-stop working under 40 degree condition.
• Tri-proof Air duct design.
• VRD adjustable.
• Arc Force adjustable.
• Hot start adjustable.
• Recommend for 5.0mm Electrode
• Suitable for Acid Electrode Basic Electrode, and Cellulosic Electrode
Technical Data :
| Model | Input Voltage/ Phase / Frequency |
Output current/ Voltage /Duty cycle (400 °c) |
Amps input at Rated output |
Output range / OCV | Dimension | Weight (kg) |
| ARC 400IJ2 | 380V/3P/50-60hz | 400A/36V/60% 310A/32.4V/100% |
27.6A@400A | 30-400A/72V/17V/(VRD) | 550*286*545 | 25 |
| ARC 500IJ | 380V/3P/50-60hz | 500A/40V/60% 387A/35.5V/100% |
35A@500A | 40-500A/82V/17V/(VRD) | 630*300*640 | 40 |
| ARC 6301 | 380V/3P/50-60hz | 630A/44V/60% 488A/39.5V/100% |
53.1A@630A | 50-630A/90V/17V/(VRD) | 650*310*640 | 54 |
